Power
8650W
-
Hashrate
865.00 TH/s
-
Efficiency
10 J/T
-
Algorithm
SHA-256
Bitmain Antminer S23e U2H Bitcoin Miner 865TH/S | BT-MINERS
WasUS$19,030.00US$13,321.00
Up to 100% better than the previous generation
Supports 24/7 continuous operation
Warranty : Come with 360 days factory warranty.
S23e U2H Profitability
Daily est.earnings
Daily est.reward
ROI
Electricity
Electricity ratio
Profit
Miner Profitability History
Description
Antminer S23e U2H Description
Bitmain Antminer S23e U2H is an ASIC miner designed for SHA-256 algorithm, specifically targeting BTC (Bitcoin) . It delivers a maximum hashrate of 865Th/s while consuming 8650W of power, resulting in an energy efficiency of 10j/Th.
*As a high efficient mining rig for cryptocurrency, this unit requires higher voltage set ups than typical miners, which may cause it to be unoperational in most homes and mining facilities. Please consult with our sales rep before placing order*
For Brand NEW Miner, Bitmain Provides 360 days of factory warranty.
Technical Specifications
| Product Glance | Value |
|---|---|
| Model | U3S23H |
| Crypto algorithm/coins | SHA256|BTC/BCH/BSV |
| Typical hashrate | 865 T |
| Power on wall @35℃, Watt | 8650 |
| Power efficiency on wall@35℃ | 10 |
| Detailed Characteristics | Value |
|---|---|
| Power Supply | |
| Phase | 3 |
| Input voltage, Volt | 380~415 |
| Input frequency range, Hz | 50~60 |
| Input max current, Amp | 24 （Power Port：LP34） |
| Hardware Configuration | |
| Networking connection mode | RJ45 Ethernet 10/100M |
| Server size(length*width*height, w/o package), mm | 600*483*86 |
| Net weight, kg | 42.0 |
| Gross weight, kg | 48.0 |
| Environment Requirements | Value |
|---|---|
| Inlet coolant temperature, °C | 20~50 |
| Coolant flow, L/min | 16.0~20.0 |
| Coolant pressure, bar | ≤3.5 |
| Working coolant | Antifreeze/Pure water/Deionized water |
| Coolant pH value | Antifreeze: 7.0~9.0 Pure water: 6.5~7.5 Deionized water：8.5~9.5 |
| Diameter of coolant pipe connector, mm | OD14 |
| Storage temperature, °C | -20~70 |
| Operation humidity(non-condensing), RH | 10~90% |
| Operation temperature,°C | -20~45 |
| Operation altitude, m | ≤2000 |
| What's in the Box | Value |
|---|---|
| Original factory mining machinery | ✓ |
| Power supply | ✓ |
| Shockproof packaging | ✓ |
Notes
(1) The hashrate value, power on wall, and power efficiency on wall are all typical values. The actual hashrate value fluctuates by ±3%, and the actual power on wall and power efficiency on wall fluctuate by ±5%.
(2) Caution: Wrong input voltage may cause server damaged.
(3) The noise is loudest when the fan is under maximum RPM(rotation per minute).
(4) When the server is used at an altitude from 900m to 2000m, the highest operating temperature decreases by 1℃ for every increase of 300m.
Estimate time
Please select your preferred product batch – Available Now (In Stock) for immediate shipment or Month Batch for delivery within your chosen timeframe. If no selection is needed, the product is in stock and ready to ship. If you haven’t received your miner after the estimated time, please contact us at [email protected], and our team will assist you promptly.
Shipping
All used miners will undergo testing by our certified technicians before shipping, which requires 3-5 business days. New miners will be shipped from our Shenzhen or Hong Kong warehouse, with international delivery taking approximately 5-10 business days via DHL. Once your order is shipped, you will receive a confirmation email with a tracking number. Shipping fees are calculated based on product type and weight, varying by region.
Returning policy
All sales are final and non-refundable after shipment, but we offer repair and replacement services if there are technical issues with your miner.
Minable pools for
Partners
Antminer S23e U2H Description
The Bitmain Antminer S23e U2H is a high-performance SHA-256 ASIC miner engineered for large-scale Bitcoin mining operations. Delivering a maximum hashrate of 865 TH/s, this model is designed for environments where operational stability, thermal efficiency, and long-term reliability are critical.
Equipped with an advanced hydro cooling (U2H) system, the S23e U2H maintains consistent performance under continuous full-load operation. Compared with traditional air-cooled miners, hydro cooling enables superior heat dissipation, reduced thermal stress on hardware components, and improved uptime in high-density mining facilities.
With a power consumption of approximately 8650 W and an energy efficiency of around 10 J/TH, the Antminer S23e U2H is optimized for professional deployments where power cost and cooling infrastructure are carefully managed. This miner is suitable for data-center-grade mining farms, containerized mining solutions, and industrial crypto mining facilities.
The Antminer S23e U2H supports Bitcoin (BTC) and other SHA-256 algorithm coins such as Bitcoin Cash (BCH) and BSV. Due to its power requirements and cooling design, this model is not intended for residential or home mining environments.
Bitmain’s Legacy and the Antminer Series
Bitmain has long been recognized as one of the most influential companies in the global cryptocurrency mining industry. Established in 2013, the company quickly became a pioneer in the development of high-performance ASIC mining hardware. Over the years, Bitmain’s engineering breakthroughs have shaped the evolution of blockchain mining, helping miners achieve higher profitability, lower energy consumption, and unprecedented operational efficiency.
At the core of Bitmain’s success is its legendary Antminer series—a lineup of ASIC miners covering major algorithms such as SHA-256, Equihash, Scrypt, Kadena, and more. Antminers are known worldwide for their stability, durability, and competitive edge in mining performance. The product line has produced some of the most iconic models in mining history, including the Antminer S9, S19 Pro, L7, Z15, and the latest next-generation units such as the S21 and Z15 Pro.
Each Antminer generation not only improves hashing efficiency but also introduces advanced chip architecture, enhanced cooling systems, and optimized firmware designed for 24/7 operation. The series has become the global standard for both home miners and industrial-scale mining farms, offering unmatched reliability and long-term performance.
Today, Bitmain continues to push the boundaries of ASIC technology, developing miners that deliver higher output with lower power consumption. The company’s commitment to quality and innovation has solidified the Antminer brand as the benchmark of professional cryptocurrency mining—trusted by millions of miners across the world.
Antminer S23e U2H vs Bitmain Antminer S23 Hyd 3U
Overview
The Antminer S23e U2H and Antminer S23 Hyd 3U are both hydro-cooled SHA-256 Bitcoin miners from Bitmain, but they target distinct deployment scales and performance tiers within professional mining operations.
| Feature | Antminer S23e U2H | Antminer S23 Hyd 3U |
|---|---|---|
| Hashrate | 865 TH/s | 1.16 PH/s (1160 TH/s) |
| Power | ~8650 W | ~11,020 W |
| Efficiency | Strong, hydro-cooled | Higher absolute efficiency (~9.5 J/TH) |
| Scale | Mid-to-large professional | Enterprise / hyperscale mining |
| Cooling | Hydro (U2H optimized) | Hydro (3U optimized) |
-
Processing&Shipping Time
-
Payment Policies
-
Taxes and Custom Duties
Processing&Shipping Time
Payment Policies
Taxes and Custom Duties
All shipments will go out by UPS or DHL.
Please contact us if any documentations are requested by customs.
Our product are excluded of all value added taxes and customs duties sold by BT-Miners. You will be solely responsible for paying any outstanding taxes and duties as per your country’s law and customs. Client will be responsible for additional shipping charges if items are returned to sender.
Contact us at store@bt-miners.tech or 813-820-0668 if you have any questions.
All products on our website are priced in US Dollars.
Payment made by credit or debit card may subject to card processing fees.
We can accept payment by credit/ debit card, wire transfer, ACH transfer (through our online portal), and crypto.
*Machine prices will fluctuate according to the current market price.*
All orders will be dispatch in the order which they were received. Pre-orders typically ships at the end of the month of the batch but may delay if manufacturer delays release/shipment. In stock machines ship in 3-7 business days from our warehouse in China. Bulk orders may release a few days later.
We always try to ship as soon as we can via USP or DHL after full payment has been received and verified.
International shipping usually takes about 5-8 business days. Due to changing regulations, we will not be able to cover duty tax for all orders entering USA. Deliveries to other countries may require customers to clear customs and pay duty tax. Please notify us right away if documents are requested by customs as improper filing may result in higher fees and/or delays.
All sales are final and non-refundable on any terms.
Want to find more Similar Miners?
FAQs
-
What Is The Lifespan Of This Mining Machine?
The lifespan of mining hardware is influenced by usage intensity, environmental factors like temperature, humidity, and dust. Proper maintenance and optimal conditions can significantly extend its longevity.
-
How Does Electricity Cost Impact Profitability?
Electricity costs play a crucial role in mining profitability, as high rates can quickly offset profit. Therefore, it is vital to access local electricity costs to determine if mining is viable. With high electricity costs and high liquidity of digital assets, investing in an energy-efficient miner becomes even more important.
-
Why Choose Antminer S23e U2H
Compared with traditional air-cooled Bitcoin miners, the S23e U2H hydro-cooled design provides:
-
More consistent performance under sustained full load
-
Improved thermal management, reducing hardware degradation over time
-
Lower noise impact, making it suitable for enclosed mining environments
-
Better compatibility with modern immersion and water-loop infrastructure
For operators focused on long-term uptime and operational stability, hydro-cooled ASIC miners offer clear advantages.
-
-
Mining Performance & ROI Considerations
The Antminer S23e U2H delivers competitive performance in the current SHA-256 mining landscape.
Actual profitability depends on:-
Electricity cost
-
Bitcoin network difficulty
-
BTC market price
-
Cooling and infrastructure efficiency
This model is best suited for miners with optimized power pricing and professional cooling systems, where its efficiency and stability can be fully utilized.
-
-
What coins can the Antminer S23e U2H mine?
The S23e U2H supports SHA-256 algorithm coins, including Bitcoin (BTC), Bitcoin Cash (BCH), and BSV.
-
Is the Antminer S23e U2H suitable for home mining?
No. Due to its power consumption and hydro cooling requirements, this miner is designed for professional and industrial environments, not residential use.
-
What are the advantages of hydro cooling?
Hydro cooling provides better heat dissipation, improved hardware longevity, and more stable performance compared to air-cooled miners, especially under continuous high load.
-
Does BT-MINERS provide support for this model?
Yes. BT-MINERS supplies authentic Bitmain hardware, with professional sales support and logistics experience serving mining operations worldwide.
-
Is this miner covered by Bitmain warranty?
Yes, the S23e U2H typically comes with a 360 days factory warranty.
-
Can BT-MINERS assist with farm-level deployment?
Yes. Our team provides support for bulk orders, logistics, and mining farm integration.
-
What infrastructure is required to run the S23e U2H?
You need hydro-cooling equipment, a 3-phase power system, proper piping, coolant, and stable ventilation.
